    • Feedwater output up to 0.5°C
    • Integrated water circulation pump
    • Stainless steel harrow exchanger
    • Ice accumulation
    • Large-capacity insulated water tank
    • Operational management PLC
    • Water level management
    • Customisation available
    • Food-grade materials and water
    • Total drainage
    MADE IN FRANCE
    Dimensions
    HEIGHT 1500 mm
    WIDTH 4100 mm
    DEPTH 1105 mm

    * Clearance height required: + 500 mm

    These chillers have been developed for industrial capacities ranging from 350 to 650 litres of water per hour.
    They are complemented by water dispensing options with cold water / hot water mixing (dispenser models DMT-MA and DMT-PROG).

    Output capacity: 350 to 650 litres / hour
    Water inlet temperature +20°C
    Water outlet temperature +1°C

    Output capacity: 700 to 1300 litres / hour
    Water inlet temperature +15°C
    Water outlet temperature +5°C

    Tank volume: 800 L

    Empty weight: 480 to 620 kg (from 1280 to 1420 kg in operation)

    Electrical power in kW: 8 to 14

    Supply voltage: 400V-3ph-50Hz

    Option:
    – Remote refrigeration unit
    – Glycol water version
    – Tropical version
    – Other voltage
