• Feedwater output up to 0.5°C
• Integrated water circulation pump
• Stainless steel harrow exchanger
• Ice accumulation
• Large-capacity insulated water tank
• Operational management PLC
• Water level management
• Customisation available
• Food-grade materials and water
• Total drainage
• Integrated water circulation pump
• Stainless steel harrow exchanger
• Ice accumulation
• Large-capacity insulated water tank
• Operational management PLC
• Water level management
• Customisation available
• Food-grade materials and water
• Total drainage
MADE IN FRANCE
Dimensions
HEIGHT 2200 mm
WIDTH 4500 mm
DEPTH 1500 mm
* Clearance height required: + 500 mm
These chillers have been developed for industrial capacities ranging from 750 to 2000 litres.
They are complemented by water dispensing options with cold water / hot water mixing (dispenser models DMT-MA and DMT-PROG).
Output capacity: 750 to 2000 litres / hour
Water inlet temperature +20°C
Water outlet temperature +1°C
Output capacity: 1500 to 4000 litres / hour
Water inlet temperature +15°C
Water outlet temperature +5°C
Tank volume: 2800 L
Empty weight: 1400 to 2300 kg (from 4200 to 5100 kg in operation)
Electrical power in kW: 16 to 37
Supply voltage: 400V-3ph-50Hz
Option:
Remote refrigeration unit
Glycol water version
Tropical version
Other voltage
